JSON Parsing Structure Code Update Request

Question 1

質問

Saju Abraham · 2025年2月3日

#JSON #ObjectScript #Ensemble #Health Connect #HealthShare

Hello All,

I need help Integrating the vendor-provided code into the current code to check if the data is an array and if it is, iterate through each item using a for each loop. Also, I need to hit every error handler code mentioned at the bottom along with the transform in both instances.

My Current Code:

/// Given a patient number in a JSON string format, this includes required transformations and makes use of
/// the MPI Query Handler to pull basic demographics from Epic.
Class CUH.Proc.DCIQGetPatient Extends Ens.BusinessProcessBPL [ ClassType = persistent, ProcedureBlock ]
{

Storage Default
{
<Type>%Storage.Persistent</Type>
}

/// BPL Definition
XData BPL [ XMLNamespace = "http://www.intersystems.com/bpl" ]
{
<process language='objectscript' request='CUH.Mess.DCIQ.JsonIn' response='CUH.Mess.DCIQ.JsonOut' height='3400' width='2000' >
<context>
<property name='JsonObjectIn' type='CUH.Mess.DCIQ.JsonInObj' instantiate='1' />
<property name='HL7QRY' type='EnsLib.HL7.Message' instantiate='0' />
<property name='HL7ADR' type='EnsLib.HL7.Message' instantiate='0' />
<property name='JsonObjectOut' type='CUH.Mess.DCIQ.JsonOutObj' instantiate='1' />
<property name='RequestNumber' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN' value='50' />
</parameters>
</property>
<property name='IsInteger' type='%Boolean' instantiate='0' />
<property name='ProcError' type='%String' initialexpression='""' instantiate='0' >
<annotation><![CDATA[Error message to be sent back in the Response.]]></annotation>
<parameters>
<parameter name='MAXLEN' value='50' />
</parameters>
</property>
<property name='ValidOriginUrl' type='%String' instantiate='0' >
<parameters>
<parameter name='MAXLEN' value='100' />
</parameters>
</property>
<property name='ValidContactType' type='%String' instantiate='0' >
<parameters>
<parameter name='MAXLEN' value='50' />
</parameters>
</property>
<property name='ValidIDNumberType' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN' value='50' />
</parameters>
</property>
<property name='ValidNHSCodeType' type='%String' initialexpression='""' instantiate='0' >
<parameters>
<parameter name='MAXLEN' value='50' />
</parameters>
</property>
</context>
<sequence xend='200' yend='3150' >
<scope xpos='200' ypos='250' xend='200' yend='2500' >
<annotation><![CDATA[Handles all errors]]></annotation>
<code name='Initialize JSON request' xpos='200' ypos='350' >
<![CDATA[ set context.JsonObjectIn = ##class(CUH.Mess.DCIQ.JsonInObj).%New()
do context.JsonObjectIn.%JSONImport(request.bodyJson)]]>
</code>
<assign name="Valid URL" property="context.ValidOriginUrl" value="##class(Ens.Util.FunctionSet).Lookup("CUH.DCIQToEpic.OriginUrl",$NAMESPACE,"",3)" action="set" xpos='200' ypos='450' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid ContactType" property="context.ValidContactType" value="##class(Ens.Util.FunctionSet).Lookup("CUH.DCIQToEpic.ContactType",$NAMESPACE,"",3)" action="set" xpos='200' ypos='550' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid IDNumberType" property="context.ValidIDNumberType" value="##class(Ens.Util.FunctionSet).Lookup("CUH.DCIQToEpic.IDNumberType",$NAMESPACE,"",3)" action="set" xpos='200' ypos='650' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<assign name="Valid NHSCodeType" property="context.ValidNHSCodeType" value="##class(Ens.Util.FunctionSet).Lookup("CUH.DCIQToEpic.NHSCodeType",$NAMESPACE,"",3)" action="set" xpos='200' ypos='750' >
<annotation><![CDATA[Environment specific]]></annotation>
</assign>
<if name='Check OriginUrl' condition='context.JsonObjectIn.meta."origin_url"=context.ValidOriginUrl' xpos='200' ypos='850' xend='200' yend='2250' >
<true>
<if name='Check Contact Type' condition='(context.JsonObjectIn.data."0"."con_type"=context.ValidContactType)||(context.JsonObjectIn.data."con_type"=context.ValidContactType)' xpos='470' ypos='1000' xend='470' yend='2150' >
<true>
<if name='Check idNumber Type' condition='(context.JsonObjectIn.data.idNumbers.GetAt(1).type)=context.ValidIDNumberType' xpos='740' ypos='1150' xend='740' yend='2050' >
<true>
<assign name="Get Request Number" property="context.RequestNumber" value="context.JsonObjectIn.data.idNumbers.GetAt(1).number" action="set" xpos='1010' ypos='1300' />
<code name='Integer pattern' xpos='1010' ypos='1400' >
<![CDATA[ set context.IsInteger = ((context.RequestNumber)?.N)]]>
</code>
<if name='Integer?' condition='context.IsInteger' xpos='1010' ypos='1500' xend='1010' yend='1950' >
<annotation><![CDATA[Checks if Requested Number sent is an Integer]]></annotation>
<true>
<transform name='Create HL7 query' class='CUH.Tran.GetDCIQJsonPatientToEpicQRYQ011' source='context.JsonObjectIn' target='context.HL7QRY' xpos='1280' ypos='1650' />
<call name='Send to MPIQueryHandler' target='MPI Query Handler' async='0' xpos='1280' ypos='1750' >
<request type='EnsLib.HL7.Message' >
<assign property="callrequest" value="context.HL7QRY" action="set" />
</request>
<response type='EnsLib.HL7.Message' >
<assign property="context.HL7ADR" value="callresponse" action="set" />
</response>
</call>
<transform name='Converts HL7 to JSON' class='CUH.Tran.EpicADRA19ToDCIQJsonPatient' source='context.HL7ADR' target='context.JsonObjectOut' xpos='1280' ypos='1850' />
</true>
<false>
<assign name="Error No Number" property="context.ProcError" value=""MRN needs to be a positive numeric value"" action="set" xpos='1010' ypos='1650' />
</false>
</if>
</true>
<false>
<assign name="Error idNumber Type" property="context.ProcError" value=""Invalid idNumber Type"" action="set" xpos='740' ypos='1300' />
</false>
</if>
</true>
<false>
<assign name="Error Contact Type" property="context.ProcError" value=""Invalid Patient Contact Type"" action="set" xpos='470' ypos='1150' />
</false>
</if>
</true>
<false>
<assign name="Error Origin Url" property="context.ProcError" value=""Origin URL not authorized!"" action="set" xpos='200' ypos='1000' />
</false>
</if>
<faulthandlers>
<catchall xpos='200' ypos='2350' xend='200' yend='350' >
<assign property="context.ProcError" value=""Error in the Json/HL7 conversion/transformation block"" action="set" xpos='200' ypos='250' />
</catchall>
</faulthandlers>
</scope>
<assign name="Assign Error to Response" property="context.JsonObjectOut.errors" value="context.ProcError" action="set" xpos='200' ypos='2600' />
<if condition='context.JsonObjectOut.errors'=""' xpos='200' ypos='2700' xend='200' yend='3050' >
<annotation><![CDATA[Check if any errors]]></annotation>
<true>
<trace name='Log the Error' value='context.JsonObjectOut.errors' xpos='470' ypos='2850' />
<assign name="Returns {}" property="response.bodyJson" value=""{}"" action="set" xpos='470' ypos='2950' />
</true>
<false>
<code name='Returns Valid Response' xpos='200' ypos='2850' >
<![CDATA[ set temp = ##class(CUH.Mess.DCIQ.JsonOut).%New()
do context.JsonObjectOut.%JSONExportToString(.temp)
set response.bodyJson = temp]]>
</code>
</false>
</if>
</sequence>
</process>
}

}

Vendor Provided Code Snippet:

Any help would be appreciated.

Thank you!

ディスカッション (0)1

続けるにはログインするか新規登録を行ってください

Question 2

質問

Manoj R · 2025年2月3日

#初心者 #VSCode #InterSystems IRIS

Hello All,

I'm new to InterSystems, just wanted to check if we can configure the Visual Studio code to use it as Studio for Intersystems development. I tried following the instructions in few posts but nothing worked. Please guide me to setup this

3 Comments

ディスカッション (3)4

続けるにはログインするか新規登録を行ってください
